Pfaff 1591

Set-up
31
9 Set-up
Observe and comply with all regulations and information in this instruction
manual.
Pay particular attention to all safety regulations!
All set-up work may only be carried out by appropriately instructed personnel.
Disconnect the machine from the electricity mains for all set-up work by operat-
ing the main switch or by removing the mains plug!
9.01 Inserting the needle
Fig. 9 - 01
2
1
Switch off the machine!
Risk of injury due to accidental machine start-up!
Only use needles of the system intended for the machine, see chapter 3 Tech-
nical Data!
 Raise and fold out the roller presser 3.
 Move the needle bar to the top position.
 Loosen the screw 1 and insert the needle 2 until you feel it stop. The long groove must
point to the left.
 Tighten the screw 1.
3
