Pfaff 3511-2/01 User Manual

Adjustment
92
Group Parameter Description User level Setting range Set value
11
1100 Operating mode of stepper 1
(puller, differential-regulation etc.)
C 0 - 1 1
1101 Rotation direction of stepper 1
1 = anti-clockwise; 0 = clockwise
C 0 - 1 1
1102 Stepping mode of stepper 1
1 = full step
2 = half-step
3 = quarter step
4 = eighth step
C 1 - 4 2
1103 Maximum current stepper 1 [%] C 1 - 100 90
1104 Reducing current stepper 1 [%] C 0 - 60 50
1105 Start-stop-time for stepper 1,
(time for one step at start-stop-speed)
C 10 - 4000 250
1106 Pulse time for stepper 1
(time for one step at pulse speed)
C 10 - 4000 820
1107 Acceleration for stepper 1
(percentage increase of speed from start-
stop to pulse speed)
C 1 - 50 8
1108 Number of brake steps of stepper 1 C 1 - 50 5
1110 Offset after reference run C 0 - 30 5
1111 Ad j ustment range of stepper 1 C 0 - 100 100
