PSR-TRISAFE-S
1-2
PHOENIX CONTACT 103503_en_03
– Qualified personnel who install and operate safety equipment in machines and
systems.
Within the context of the safety notes in this documentation, qualified personnel are persons
who, because of their education, experience and instruction, and their knowledge of
relevant standards, regulations, accident prevention regulations, and service conditions,
have been authorized to carry out any required operations, and who are able to recognize
and avoid any possible dangers.
Documentation
Safety of personnel and
equipment
The safety of personnel and equipment can only be assured if the safe functional blocks are
used correctly (see "Intended use" on page 1-7).
Error detection Depending on the wiring and parameterization of the inputs and outputs, the
PSR-TRISAFE-S safety module can detect various errors within the safety equipment
(e.g., cross circuits).
Observe startup behavior Some of the safe functional blocks in the SAFECONF configuration software have
parameters for specifying a startup inhibit and/or a restart inhibit. An active startup
inhibit/restart inhibit can be removed by pressing a reset button that is connected and
appropriately wired to the safety module.
Use these parameters in the SAFECONF configuration software to monitor the
startup/restart of the PSR-TRISAFE-S safety module.
Do not carry out any
repairs, do not open the
housing
In the event that an error caused by reconfiguring or modifying the wiring, etc. cannot be
removed, please contact Phoenix Contact immediately.
You must observe all information in this documentation as well as in the documentation
listed in "Documentation" on page 1-8.
NOTE: Please note that responsibility for fault avoidance lies with the user.
WARNING: Repair work may not be carried out on the PSR-TRISAFE-S safety
module. It is strictly prohibited to open the safety module housing.
