Phoenix Contact PSR-TRISAFE-S User Manual

For your safety
103503_en_03 PHOENIX CONTACT 1-1
1For your safety
1.1 Purpose of this manual
This manual should enable the user to set up, configure, and start up the PSR-TRISAFE-S
configurable safety module according to the relevant safety requirements and the risk
analysis performed.
The user manual is therefore designed as a complete system description, which provides
an introductory system overview, then describes the PSR-TRISAFE-S configurable safety
module and the associated SAFECONF configuration software in detail, and finally explains
the necessary steps for configuration and startup.
For additional information and detailed step-by-step instructions for SAFECONF, please
refer to the online help for the configuration software.
This user manual is oriented exclusively to qualified electrical engineers and safety
specialists, application programmers, and software engineers, who are familiar with the
relevant safety concepts of automation technology as well as applicable standards and
other regulations. Please also read the "Qualified personnel" section in "General safety
notes" on page 1-1.
1.2 General safety notes
Requirements Knowledge of the following is required:
– The PSR-TRISAFE-S safety module used and the I/O devices (extension units,
sensors, actuators)
– The SAFECONF configuration software
– The safety directives for the field of application
Qualified personnel
This user manual is therefore aimed at:
– Qualified personnel who plan and design safety equipment for machines and systems
and are familiar with regulations governing safety in the workplace and accident
prevention.
The PSR-TRISAFE-S configurable safety module is referred to in this documentation as
"safety module" for short.
WARNING: Personal injury and damage to equipment if these safety notes are not
followed. When working with the PSR-TRISAFE-S safety module, please observe
all the safety notes included in this section.
WARNING: In the context of the use of the PSR-TRISAFE-S safety module with
SAFECONF configuration software and safe functional blocks, the following
operations may only be carried out by qualified personnel:
– Planning, parameterization, configuration (development of safety logic)
– Installation, startup, servicing
– Maintenance, decommissioning
