Pioneer PDP-5000EX Service Manual

PDP-5000EX
111
5678
56
7
8
C
D
F
A
B
E
Conversion charts for electronic VRs
Setting Value
(Step)
Vprst (V)Vofs (V)
14 15
15 21
16 26
17 31
18 36
19 42
20 47
21 52
22 58
23 63
24 68
25 73
26 79
27 84
28 89
29 94
30 99
31 104
32 110
33 115
34 120
35 125
36 130
37 136
38 141
39 146
40 151
41 155
42 160
43 165
44 170
45 175
46 180
47 185
48 191
49 196
50 201
51 206
52 211
53 216
54 222
55 227
56 232
57 237
58 242
59 248
60 255
Setting Value
(Step)
213 3
214 6
215 9
216 12
217 16
218 18
219 21
220 25
221 28
222 31
223 35
224 38
225 41
226 45
227 48
228 51
229 55
230 58
231 62
232 64
233 68
234 71
235 74
236 78
237 81
238 84
239 88
240 91
241 95
242 98
243 101
244 105
245 108
246 112
247 115
248 119
249 121
250 124
251 128
252 131
253 135
254 138
255 141
256 145
257 148
258 152
259 155
Vprst (V)
Setting Value
(Step)
260 158
261 162
262 165
263 168
264 171
265 174
266 177
267 181
268 184
269 188
270 191
271 195
272 198
273 201
274 205
275 208
276 211
277 214
278 217
279 221
280 224

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
