Pioneer PDP-5000EX Service Manual

PDP-5000EX
113
5678
56
7
8
C
D
F
A
B
E
Example:
Initial value of the set Ofs: 33 V
Tentative set value of Ofs (Ofs set value for the panel inspection): 35 V
VOL OFFSET_min1 (pale purpel): 19 V
VOL OFFSET_min2 (light blue): 17 V
VOL OFFSET_min3 (violet): 15 V
• The transition process for VOL OFFSET_max is the same as the above.
Ofs voltage (V)
White
Pale purple
Ofs15V Ofs15V Ofs15V
Completed
Full white Full white
Violet
Light blue
A luminescent
spot disappears.
A luminescent
spot disappears.
36
34
32
30
28
26
24
22
20
18
16
14
12
A luminescent spot appears.
Measure the lower limit of
the Ofs voltage.
A luminescent spot appears.
Measure the lower limit of
the Ofs voltage.
A luminescent spot does not
appear. The lower limit of the
Ofs voltage is 15 V.
VOL OFFSET_min1 VOL OFFSET_min2 VOL OFFSET_min3
Transition of the Ofs voltage during adjustment of VOL OFFSET_min

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
