PDP-5000EX
27
5678
56
7
8
C
D
F
A
B
E
KN2202-2208,2301-2307 ANK1841
CN2351 CONNECTOR B9B-EH
CN2353 CONNECTOR AKM1277
CN2354,2356 CONNECTOR AKM1281
CN2355,2357 CONNECTOR AKM1276
RESISTORS
R 2202,2206 RS3LMF561J
R 2211,2214 RS3LMF3R9J
R 2275 RS3LMF181J
R 2288-2293 RS3LMF5R6J
R 2301,2303,2307,2308 RS1/10S100J
R 2302,2304 RS1/10S0R0J
R 2305,2311 ACN1168
R 2351 ACN1162
Other Resistors RS1/16S###J
CAPACITORS
C 2211,2223,2233,2243 CEHAT470M25
C 2212,2272 CKSRYF104Z50
C 2221,2231,2241,2253 CKSYB105K25
C 2222,2232,2242,2290 CKSRYB104K16
C 2251 CCSRCH331J50
C 2252,2362 CKSRYB105K10
C 2256,2271,2291,2352 CEHAT470M25
C 2273,2281 CEHAT2R2M2E
C 2284,2286 ACE1163
C 2292 CKSYB105K25
C 2299 CKSRYB104K25
C 2301,2305 ACH1445
C 2302-2304,2306-2308 ACE1180
C 2309,2310 CCG1186
C 2351,2353,2361,2363 CEHAT470M16
C 2354,2359,2364,2380 CKSRYB104K16
C 2356,2357 ACH1449
C 2358 CEHAT101M10
C 2360 CKSRYB473K16
C 2367,2368 CEHAT101M25
C 2369 CEHAT470M16
C 2381 CKSRYB104K16
• Block Name: Y SCAN BLOCK
SEMICONDUCTORS
IC 2401,2403,2409 TLP116
IC 2402,2407,2421,2490 TC74AC540FT
IC 2404-2406,2408,2410 PS9117
IC 2481,2482 PST3638UR
MISCELLANEOUS
L 2401 BTH1136
L 2402,2403 BTH1134
F 2401,2402 ATX1062
CN2401,2402 15P CONNECTER AKM1200
RESISTORS
R 2405,2417 RAB4C220J
Other Resistors RS1/16S###J
CAPACITORS
C 2401,2407,2414 CEHAT101M10
C 2402,2403,2405,2406 CKSRYB104K16
C 2404,2411 ACH1413
C 2408-2410,2412,2413 CKSRYB104K16
C 2415,2420,2421 CKSRYB104K16
Mark No. Description Part No.
C 2417,2418 ACE1181
C 2481,2482 CKSRYB102K50
• Block Name: Y VH DD CON BLOCK
SEMICONDUCTORS
IC 2501,2551 MIP2E3DMU
IC 2502,2552 PS2701A-1(L)
IC 2508,2557 TA76431FR
IC 2553 BA10358F
Q 2501 HN1C01FU
Q 2551 2SC2412K
D 2501 U1ZB330
D 2502 D1FL40
D 2503,2505,2555,2556 CRH01
D 2504,2551,2552,2554 CRF03
D 2506 UDZS6R2(B)
D 2507 UDZS12(B)
D 2558 1SS355
D 2559 UDZS4R7(B)
MISCELLANEOUS
VR2501 CCP1390
VR2551 CCP1392
T 2501 ATK1158
T 2551 ATK1153
RESISTORS
R 2509 RAB4C472J
R 2551,2552 RS1/10S1803F
R 2554 RS1/10S2203F
R 2557,2560 RS1/16S5601F
R 2564 RS1/16S1002F
R 2565 RS1/16S2202F
R 2566 RS1/16S4702F
R 2567 RS1/16S6801F
R 2568-2570 RS1/10S224J
Other Resistors RS1/16S###J
CAPACITORS
C 2502,2507,2553,2561 CKSRYB104K16
C 2503,2554 CEHAT101M16
C 2505,2555 CEHAT101M25
C 2506 ACH1450
C 2508 CEHAT221M16
C 2509 CEHAT470M25
C 2551 ACH1448
C 2552 ACH1451
C 2556 CKSRYF104Z50
C 2557,2559,2560 CKSRYB104K25
C 2558 CEHAT221M25
C 2562 CCG1186
• Block Name: Y DD CON BLOCK
SEMICONDUCTORS
IC 2601 PS2701A-1(L)
IC 2605,2657 TA76431FR
IC 2651 MIP2E3DMU
IC 2652,2654,2658 TLP181(P-GR)
IC 2653 BA10358F
Mark No. Description Part No.
