Pioneer PDP-5000EX Service Manual

PDP-5000EX
34
1234
1234
C
D
F
A
B
E
IC 8208 NJU26901E2
Q 8201,8202 2SA1586
Q 8203,8204,8211,8212 2SC4116
Q 8213 DTA124EUA
Q 8215,8216 HN1B04FU
D 8201 UDZS2R4(B)
MISCELLANEOUS
L 8211 BTH1111
JA 8201-8206 JACK PKB1029
X 8201 CRYSTAL ASS1204
CN8201 CONNECTOR 11P AKM1359
CN8202 PLUG(15P) KM200NA15
RESISTORS
R 8241-8244,8334 RS1/16S222J
R 8247,8248,8343-8346 RS1/16S102J
R 8249-8252 RS1/16S473J
R 8255,8256 RS1/16S272J
R 8257,8258,8320,8321 RS1/16S223J
R 8259-8262 RS1/16S3301F
R 8263-8266 RS1/16S101J
R 8267-8275,8325,8326 RS1/16S0R0J
R 8280 RAB4CQ103J
R 8281,8322 RAB4CQ470J
R 8301,8302,8335,8336 RS1/16S182J
R 8333 RS1/16S472J
R 8349-8355 RS1/16S0R0J
R 8356 RS1/16S470J
Other Resistors RS1/16SS###J
CAPACITORS
C 8201-8212,8221-8224 CKSRYB105K10
C 8219,8234,8250,8253 CKSSYF104Z16
C 8220,8277,8278,8307 DCH1165
C 8235,8239,8285,8286 CKSRYB105K10
C 8237,8287 CEHAT101M10
C 8238,8272,8296,8298 ACG7046
C 8254,8261,8263,8264 CKSSYF104Z16
C 8255-8258 CEHAT100M50
C 8262 CEHAT220M50
C 8265-8268 CKSRYB102K50
C 8269,8271,8283,8284 CKSSYF104Z16
C 8270,8316 CEHAT101M16
C 8274 ACG1122
C 8279,8280 CCSRCH681J50
C 8281,8282 CCSRCH181J50
C 8289-8292,8317,8318 CKSRYB105K10
C 8293,8294 CKSSYB681K50
C 8295,8297,8299-8301 CKSSYF104Z16
C 8302,8304,8305 ACG7046
C 8303 CKSSYF104Z16
>
C 8306 CCSSCH221J50
C 8308 DCH1165
C 8309,8310 CKSSYB152K50
C 8311,8312 CCSRCH331J50
C 8313-8315 CKSSYB104K10
Mark No. Description Part No.
Unit Name: FHD SP LR1 ASSY
MISCELLANEOUS
>
L 8402 ATF1206
CN8401 3P TOP POST B3B-EH
CN8402 SPEAKER TERMINAL 2-P AKE1041
RESISTORS
R 8404,8408 RD1/2MMF100J
Other Resistors RS1/16S###J
CAPACITORS
C 8403,8404 CCSRCH101J50
C 8405 CKSRYB332K50
C 8406,8409,8410 CCSRCH221J50
C 8407 CKSRYF473Z50
>
C 8411,8412 CCSRCH221J50
Unit Name: FHD SP LR2 ASSY
MISCELLANEOUS
>
L 8502 ATF1206
CN8501 3P TOP POST B3B-EH
CN8502 SPEAKER TERMINAL 2-P AKE1041
RESISTORS
R 8504,8508 RD1/2MMF100J
Other Resistors RS1/16S###J
CAPACITORS
C 8503,8504 CCSRCH101J50
C 8505 CKSRYB332K50
C 8506,8509,8510 CCSRCH221J50
C 8507 CKSRYF473Z50
>
C 8511,8512 CCSRCH221J50
Unit Name: FHD LED ASSY
SEMICONDUCTORS
D 8601 TLRV1022
D 8602 SML512BC4T
MISCELLANEOUS
CN8601 L-PLUG(3P) KM200NA3L
RESISTORS
All Resistors RS1/16S###J
Unit Name: FHD FAN CONNECT ASSY
SEMICONDUCTORS
Q 8651,8652 DTC124EUA
D 8651,8652 DAN202U
RESISTORS
All Resistors RS1/16SS###J
Mark No. Description Part No.

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
