D15 : CN3614 (AKM1348) Y1: CN2001 (AKM1348)
FHD DIGITAL ASSY
50FHD Y DRIVE ASSY
Pin No. Name Voltage [V] Name Pin No. Function
1 SCN5V_PD 0 SCN5V_PD 40 Y DRIVE PD signal input
2NC-NC 39 Non-connection termial
3 CLK1 0 3.3 CLK1 38 SCAN control signal output
4 SI_H 0 3.3 SI_H 37 SCAN control signal output
5 SI_L 0 3.3 SI_L 36 SCAN control signal output
6 DGND 0 DGND 35 GND
7 CLR 0 3.3 CLR 34 SCAN control signal output
8 CLK2 0 3.3 CLK2 33 SCAN control signal output
9 DGND 0 DGND 32 GND
10 LE 0 3.3 LE 31 SCAN control signal output
11 OC2_U 0 3.3 OC2_U 30 SCAN control signal output
12 OC1 0 3.3 OC1 29 SCAN control signal output
13 DGND 0 DGND 28 GND
14 YSUS-B 0 3.3 YSUS-B 27 Y DRIVE control signal output
15 YSUS-U 0 3.3 YSUS-U 26 Y DRIVE control signal output
16 DGND 0 DGND 25 GND
17 YSUS-D 0 3.3 YSUS-D 24 Y DRIVE control signal output
18 YSUS-G 0 3.3 YSUS-G 23 Y DRIVE control signal output
19 DGND 0 DGND 22 GND
20 YPR-U 0 3.3 YPR-U 21 Y DRIVE control signal output
21 SUS_MUTE 0 5.0 SUS_MUTE 20 Y DRIVE mute signal output
22 DGND 0 DGND 19 GND
23 YSUS-MSK 0 3.3 YSUS-MSK 18 Y DRIVE control signal output
24 YNRST 0 3.3 YNRST 17 Y DRIVE control signal output
25 YRSV2 - YRSV2 16 Y DRIVE control signal output (Reserve)
26 DGND 0 DGND 15 GND
27 YNOFS 0 3.3 YNOFS 14 Y DRIVE control signal output
28 YRSV3 - YRSV3 13 Y DRIVE control signal output (Reserve)
29 YSOFT-D 0 3.3 YSOFT-D 12 Y DRIVE control signal output
30 OC2_D 0 3.3 OC2_D 11 SCAN control signal output
31 DGND 0 DGND 10 GND
32 VOFS_ADJ 0 3.3 VOFS_ADJ 9 Vofs offset adjustment signal output
33 VYPRST_ADJ 0 3.3 VYPRST_ADJ 8 Reset voltage adjustment signal output
34 DGND 0 DGND 7 GND
35 NC - NC 6 Non-connection termial
36 SCAN_PD 0 SCAN_PD 5 Y DRIVE PD signal input
37 YDD_PD 0 YDD_PD 4 Y DRIVE PD signlal input
38 YSUS_PD 0 YSUS_PD 3 Y DRIVE PD signlal input
39 NC - NC 2 Non-connection termial
40 YDRV_PD 0 YDRV_PD 1 Y DRIVE PD signal input
