Pioneer PDP-5000EX Service Manual

PDP-5000EX
98
1234
1234
C
D
F
A
B
E
Terminal Panel (F)
3
4
Remove the Ferrite Core.
Remove the cable from the wire saddle.
5
55
5 5
Ferrite Core
1
Remove the two screws.(TBZ40P080FTB)
Remove the seven screws.(AMZ30P060FTB)
2
Remove the two screws.(AMZ30P060FTB)
3
11
2 2
2
3 3
2
2 2 2
4 -24 -1 4 -24 -1
Ferrite Core
Disassembly (3)

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
