Page #14 background image
Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
14
1.4 Product Features
Physical Port
5-port 10/100/1000BASE-T Gigabit RJ45 copper with 4-port IEEE 802.3at/af PoE injector function
(Port 1 to Port 4)
RJ45 type interface for basic management and setup
USB type A female for setting file backup and restoration
Power over Ethernet
Complies with IEEE 802.3at Power over Ethernet Plus end-span PSE
Backward compatible with IEEE 802.3af Power over Ethernet
Up to 4 ports of IEEE 802.3af/802.3at devices powered
Supports PoE power up to 36 watts for each PoE port
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100 meters
PoE management
- Total PoE power budget control
- Per port PoE function enable/disable
- PoE port power feeding priority
- Per PoE port power limitation
- PD alive check
- PoE schedule
Battery Management
Battery type option: Lithium battery or lead-acid battery
Easy diagnostic of the system operating status via LED indicator
Current battery usage status
Low voltage cut-off protection: Send alert and cut off power when the battery is low
MPPT (Maximum Power Point Tracking) Charge Controller
- Reverse current protection to prevent the current circuits from flowing back to the PV panel
- Over-current protection
- Reverse polarity protection (for battery and charging electrodes)
Industrial Case and Installation
IP30 aluminum case
DIN-rail and wall-mounted designs
Supports -10 to 60 degrees C operating temperature
Supports ESD 6KV DC Ethernet protection
Redundant power supply
24V~45V DC wide power input
