Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
16
1.5 Product Specifications
Product BSP-360
Hardware Specifications
Copper Ports
LAN: 5 10/100/1000Mbps auto MDI/MDI-
X RJ45 port (Port 1 to Port 5, bridge
mode)
WAN: 1 10/100/1000Mbps auto MDI/MDI-
X RJ45 port (Port 5, gateway
mode)
PoE Injector Port 4 ports with 802.3af/802.3at PoE injector function (Port 1 to Port 4)
USB 1 USB Type A female for setting backup
Power Output
4 PoE out 51VDC; max. 36 watts per PoE port
2 DC out 24@ 2A maximum (four-pin terminal block)
* The voltage of DC out is based on the battery.
Reset Button
< 5 sec: System reboot
> 10 sec: Factory default
Connector
Removable 6-pin terminal block
Pin 1/2 for PV panel; Pin 3/4 for alarm; Pin 5/6 for battery
Alarm
1 digital output (DO):
Level 0: -24V~2.1V (±0.1V)
Level 1: 2.1V~24V (±0.1V)
Open collector to 24V DC, 100mA max.
Power Requirements
PV in: 24~45V DC
Battery in/out: 24V DC
Power Consumption/
Dissipation
5.04 watts, 17.1BTU (Standby without PoE function)
6.96 watts, 23.7 BTU (Full loading without PoE function)
135.36 watts, 461.5 BTU (Full loading with PoE function)
Dimensions (W x D x H) 89 x 107 x 152 mm
Weight 1251g
ESD Protection
6KV DC
Enclosure IP30 aluminum case
Installation DIN-rail kit and wall-mount ear
LED Indicators
3 LEDs for System and Power:
- Green: Power
- Red: Alarm
- Green: PV System
4 LEDs for PoE Copper Ports (Port 1~Port 4):
- Green: LNK/ACT
- Amber: PoE-in-use
1 LED for 10/100/1000T Copper Port (Port 5):
- Green: LNK/ACT
3 LEDs for PoE Power Usage (W)

Planet Switch Specifications

General

Form Factor	Desktop
Port Speed	10/100/1000 Mbps
MAC Address Table	8K
Switching Capacity	16 Gbps
Operating Temperature	0 to 50°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
