Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
53
4.4.1.2 Statistics
This page shows the packet counters for transmission and reception regarding Ethernet network as the
screen in Figure 4-4-4 appears. Table 4-4-3 describes the Statistics Objects Screen of Renewable Energy
Switch.
Figure 4-4-
4
: Statistics Web Page Screen
Object Description
Transmit
It shows the statistic count of sent packets on the Ethernet LAN interface.
Receive
It shows the statistic count of received packets on the Ethernet LAN
interface.
Refresh
Click refresh to refresh the statistic counters on the screen.
Table 4-4-
3
: Descriptions of the Statistics Objects

Planet Switch Specifications

General

Form Factor	Desktop
Port Speed	10/100/1000 Mbps
MAC Address Table	8K
Switching Capacity	16 Gbps
Operating Temperature	0 to 50°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
