Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
6
1. INTRODUCTION
1.1 Package Contents
Open the box of the Renewable Energy Switch and carefully unpack it. The box should contain the following
items:
 The BSP-360 x 1
 Quick Installation Guide x 1
 Wall Mounting Kit x 1
 DIN-rail Kit x 4
 RJ45 Dust Cap x 2
 PV/Bat. 6-pin Terminal Block x 1
 DC Out 4-pin Terminal Block x 1
If any of the above items are missing, please contact your seller immediately.

Planet Switch Specifications

General

Form Factor	Desktop
Port Speed	10/100/1000 Mbps
MAC Address Table	8K
Switching Capacity	16 Gbps
Operating Temperature	0 to 50°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
