Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
69
4.7.3 Preview – Snapshot
This section provides snapshot from ONVIF IP cam of Renewable Energy Switch as screen in Figure 4-7-4
appears and Table 4-7-3 shows.
Figure 4-7-3: View Snapshot Web Page Screen
Object Description
Mode
Show the IP cam model.
MAC Address
Show the IP cam MAC address.
IP Address
Show the IP cam IP address.
Location
Show the IP cam IP location information in ONVIF data.
Description
Show the IP cam IP description information in ONVIF data.
Username
For security, please enter the IP cam login username to do snapshot.
Password
For security, please enter the IP cam password to do snapshot.
Get Snapshot
Press this button to get snapshot from the IP cam in the same sub-net.
Save
Press this button to save the username and password.
Reset
Press this button to revert to previously saved values.
Table 4-7-3: Descriptions of the ONVIF Device List Objects
