Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
21
Item Interface Description
1 Port-1~Port-4 4 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports with 802.af/at PoE+ injector function.
2 Port-5
One 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port.
Port-5 functions as WAN port when the operation mode of BSP-360 is
“Gateway mode”
3 USB
Connect the USB storage to USB port and back up the configuration file.
4 Reset Button
< 5 seconds: System reboot.
> 10 seconds: Factory default.
5
4-pin T
Block
2 x 24V 2A DC output connector.
The output voltage is the same as battery voltage.
Maximum power output is clamped at 48W.
2.1.2 LED Indicators
The front panel LEDs indicates instant status of system power, PoE and PV system, management port
Link/Active, PoE power usage status and per PoE port links status, thus helping administrator to monitor and
troubleshoot when needed.
System
LED Color Function
PWR Green On
To indicate BSP-360 has power.
Alarm Red
Slow Blinks To indicate PV < 24V.*
Fast Blinks
To indicate battery Voltage
LVD.*
PV System Green
Slow Blinks To indicate the system is “Not Charging”.
Fast Blinks To indicate the battery is “ Charging”
50W Amber On To indicate the system consumes over 50-watt PoE power budget.
100W Amber On To indicate the system consumes over 100-watt PoE power budget.
120W Amber On To indicate the system consumes the total 120-watt PoE power budget.
*The detection voltage will have a tolerance of +-0.7V.
PoE 10/100/1000BASE-T Interfaces (Port-1 to Port-4)
LED Color Function
LNK/ACT Green Blinks
To indicate the link through that port is successfully established.
PoE Amber
Lights
To indicate the port is providing DC in-line power.
Off
To indicate the connected device is not a PoE powered device (PD).
10/100/1000BASE-T Interfaces (Port-5)
LED Color Function
LNK/ACT Green Blinks
To indicate the link through that port is successfully established.
