Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
29
2.2.2 DIN-rail Mounting
This section describes how to install the Renewable Energy Switch. There are two methods to install the
Renewable Energy Switch -- DIN-rail mounting and wall-mount plate mounting. Please follow the steps below.
Follow all the DIN-rail installation steps as shown in the example.
Step 1: Screw the DIN-rail on the Renewable Energy Switch.
Step 2: Lightly slide the DIN-rail into the track.
Step 3: Check whether the DIN-rail is tightly on the track.
Please refer to the following steps to remove the Renewable Energy Switch from the track.

Planet Switch Specifications

General

Form Factor	Desktop
Port Speed	10/100/1000 Mbps
MAC Address Table	8K
Switching Capacity	16 Gbps
Operating Temperature	0 to 50°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
