Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
80
APPENDIX B.
B.1 Recommended Use of the Connected Wires
The wire gauges for the current are shown below:
(Applicable to the system with voltage attenuation less than 3%)
Gauge Diameter Amp
AWG #16 1.295 10.00
AWG #17 1.143 8.40
AWG #18 1.016 6.40
AWG #19 0.914 5.20
AWG #20 0.813 4.00
B.2 Recommended Settings for Different Batteries
We suggest Nickel-cadmium battery and Lead-acid battery for BSP-360. You could set the Battery type at
Battery Management on the web.
Use Lead-acid battery for BSP-360. You could set the Battery type at Battery Management on the web of
BSP-360.
