Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
22
2.1.3 Upper Panel
The Upper Panel of the Renewable Energy Switch comes with a DC inlet power socket and one terminal
block connector with 6 contacts.
PV In Connector
Battery In/Out
The wire gauge for the terminal block should be in the range from 16 to 20 AWG.

Planet Switch Specifications

General

Form Factor	Desktop
Port Speed	10/100/1000 Mbps
MAC Address Table	8K
Switching Capacity	16 Gbps
Operating Temperature	0 to 50°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
