Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
20
2. INSTALLATION
This section describes the hardware features of Renewable Energy Switch. For easier management and
control of the Renewable Energy Switch, familiarize yourself with its display indicators and ports. Front panel
illustrations in this chapter display the unit LED indicators. Before connecting any network device to the
Renewable Energy Switch, read this chapter carefully.
2.1 Hardware Description
The section describes the hardware of the Renewable Energy Switch and gives a physical and functional
overview.
2.1.1 Injector Front Panel
Dimensions (W x D x H)
152 x 107 x 89 mm
Weight
1251g (gross weight)

Planet Switch Specifications

General

Form Factor	Desktop
Port Speed	10/100/1000 Mbps
MAC Address Table	8K
Switching Capacity	16 Gbps
Operating Temperature	0 to 50°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
