Planet Switch User Manual

Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
33
3.3 Management Method
User can manage the Renewable Energy Switch by Web Management via a network connection.
3.3.1 Web Management
The following shows how to start up the Web Management of the BSP-360. Note the BSP-360 is configured
through an Ethernet connection. Please make sure the manager PC must be set to the same IP subnet
address.
For example, the default IP address of the BSP-360 is 192.168.0.100, then the manager PC should be set to
192.168.0.x (where x is a number between 1 and 254, except 100), and the default subnet mask is
255.255.255.0.
Logging in to the BSP-360
Step 1. Use Internet Explorer 8.0 or above for Web browser and enter IP address http://192.168.0.100 (the
factory default IP address) to access the Web interface.
Step 2. When the following dialog box appears, please enter the default user name “admin” and password
“admin” (or the password you have changed before).
Default IP Address: 192.168.0.100
Default User Name: admin
Default Password: admin
