Firewall
NAT firewall with SPI (Stateful Packet Inspection)
Built-in NAT server supporting Port Forwarding, and DMZ
Built-in firewall with IP address/MAC address/Port/ URL filtering
Supports ICMP-FLOOD, UDP-FLOOD, TCP-SYN-
FLOOD filter, DoS
protection
Routing Protocol Static/Dynamic (RIP1 and 2) routing
VPN Pass-through PPTP, L2TP, IPSec, IPv6
LAN
Built-in DHCP server supporting static IP address distribution
Supports UPnP, Dynamic DNS
Supports IGMP Proxy
Supports 802.1d STP (Spanning Tree)
IP/MAC-based bandwidth control
Management
Management Interface
Setting up of system/management functions
Web firmware upgrade
SNMP trap for alarm notification of events
PoE Management
Power limit by consumption and allocation
PoE admin mode
Per port power schedule
Per port power enable/disable
Power feeding priority
Current per port usage and status
Total power consumption
PD alive check
Scheduled power recycling
Battery Management
Current battery usage status
Low voltage cut-off protection
Fully-charged hold time protection
PLANET ONVIF IP Camera
Management
Supports PLANET ONVIF IP camera discovery
A maximum of four PLANET ONVIF IP cameras can be powered by one
BSP-360 switch.
Supports IP camera snapshot function in the LAN.
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3x Flow Control and Back Pressure
IEEE 802.1D Spanning Tree Protocol
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
RFC 768: UDP
RFC 791: IP

Planet Switch Specifications

General

Form Factor	Desktop
Port Speed	10/100/1000 Mbps
MAC Address Table	8K
Switching Capacity	16 Gbps
Operating Temperature	0 to 50°C
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
