Industrial Renewable Energy 4-Port 10/100/1000T
802.3at PoE+ Managed Ethernet Switch/Router
BSP-360
59
Object Description
Profile1
Profile2
Profile3
Profile4
This function is available when choosing schedule on each port.
Power Mode
Allows user to select AT/AF compatibility mode. The default value is AT
mode.
Indicates the power inline mode.
Priority
The Priority represents PoE ports priority. There are three levels of power
priority named Low, High and Critical.
The priority is used in case the total power consumption is over the total
power budget. In this case the port with the lowest priority will be turned off,
and power is provided to the port of higher priority.
Device Class
Displays PoE class level.
The IEEE 802.3af standard offers PoE class level from 1 to 3 and IEEE
802.3at standard offers the class from 1 to 4.
Current Used [mA] The Power Used shows how much current the PD currently is using.
Power Used [W] The Power Used shows how much power the PD currently is using
Power Limit [W]
It can limit the port PoE supply watts. Per port maximum value must be less
than 36 watts. Total port values must be less than the Power Reservation
value. Once power overload is detected, the port will auto shut down and
keep in detection mode until PD’s power consumption is lower than the
power limit value.
Apply
Press this button to take effect.
Refresh
Press this button to refresh the current Web page.
Auto-Refresh
Check this box to refresh the page automatically. Automatic refresh occurs
every 3 seconds.
Table 4-6-1: Descriptions of the PoE Configuration Objects
