Planmeca Sovereign 23
INSTALLING THE CUSPIDOR
Installation manual
Insert the lock washers to the anchors (1) and rotate them to the position shown on the figure
below (2). Insert the washers (3) and nuts (4).
S3_1.eps
1
3
4
2
