INSTALLING THE CUSPIDOR
30 Planmeca Sovereign
Installation manual
Patient chair
The angle of the patient chair can be chosen from six predetermined positions (3 positions /
handedness). You can change the patient chair position as follows.
Unscrew the seat rotation locking screw (1). Turn the seat to the desired position (2). Attach
the rotation locking screw (1).
After changing the cuspidor installation position you also have to change the patient chair
position 180° (±15°) (3).
15°
15°
S179.eps
1
2
3
