INSTALLING THE PYLON AND ARMS
76 Planmeca Sovereign
Installation manual
Connect the cables as shown on the figure below.
Cover the water tube connections with protective sleeves as shown on the figure above.
P4P3P2
LOCAN
SELV
P1 P7
SELV
Mini-Fit 4
Mini-Fit 6
LOCAN
Micro-Fit 4
EMEIO
Micro-Fit 4
EMEIO
P7 P1
P4 P3
P8
Return water
Water IN
Air IN
S23_3.eps
S-Video
Protective sleeveProtective sleeve
