INSTALLING THE PYLON AND ARM ACCESSORIES
88 Planmeca Sovereign
Installation manual
The friction of the tray arm movements can be adjusted. Loosen the joint attachment screw
using a 3 mm Allen key (1). Rotate the plate manually and move the tray arm (2). Hold the
plate in position with pliers (3) and tighten the attachment screw (4).
1
2
4
S142_3.eps
3
