Planmeca Sovereign - Monitor Installation on Pylon

Planmeca Sovereign 89
INSTALLING THE PYLON AND ARM ACCESSORIES
Installation manual
The angle of the tray table can be adjusted as follows. Loosen the securing screws (1) and
adjust the angle (3) with four adjustment screws (2). Tighten the securing screws.
S252.eps
1
2
3
