3D ENT programs, Planmeca Viso G7
Program Preset volume
size
Volume range Note
Nose Ø80 × 80 mm Ø70 × 50 mm – Ø120 × 100 mm
10 mm steps
Sinus Ø130 × 130 mm Ø100 × 100 mm – Ø160 × 160 mm
10 - 20 mm steps
Middle Ear Ø50 × 50 mm Ø30 × 30 mm – Ø60 × 60 mm
5 mm steps
75 µm voxel possible
only with volumes
smaller than 70 x 70 mm
Temporal
bone
Ø80 × 80 mm Ø70 × 50 mm – Ø120 × 100 mm
10 mm steps
Airways Ø90 × 100 mm Ø80 × 80 mm – Ø100 × 140 mm
10 mm steps
Vertebrae Ø80 × 100 mm Ø80 × 80 mm – Ø100 × 140 mm
10 mm steps
3D programs, Planmeca Viso G5
Program Preset volume
size
Volume range Note
Tooth Ø50 × 50 mm Ø30 × 30 mm – Ø60 × 60 mm
5 mm steps
75 µm voxel possible
only with volumes
smaller than 70 x 70 mm
TMJ Ø50 × 50 mm Ø30 × 30 mm – Ø60 × 60 mm
5 mm steps
Teeth Ø90 × 90 mm Ø70 × 30 mm – Ø90 × 90 mm
10 mm steps
Jaw Ø140 × 100 mm Ø100 × 30 mm – Ø200 × 100 mm
10 mm steps
Face Ø160 × 160 mm Ø140 × 130 mm – Ø200 × 170 mm
10 mm steps
3D ENT programs, Planmeca Viso G5
Program Preset volume
size
Volume range Note
Nose Ø80 × 80 mm Ø70 × 50 mm – Ø90 × 90 mm
10 mm steps
Sinus Ø130 × 130 mm Ø100 × 100 mm – Ø200 × 150 mm
10 - 20 mm steps
Middle Ear Ø50 × 50 mm Ø30 × 30 mm – Ø60 × 60 mm
5 mm steps
75 µm voxel possible
only with volumes
smaller than 70 x 70 mm
Temporal
bone
Ø80 × 80 mm Ø70 × 50 mm – Ø90 × 90 mm
10 mm steps
11 3D exposure
