FAULT CODE DESCRIPTIONS
TR-204
Fault Code TR-204, indicates that at “initialization” or during Run, the Outfeed sensor Trimmer (TR-
Q6), was blocked exceeding timeout.
Initial Actions
Check fuse F2 on Transformer.
Make sure that the Outfeed sensor Trimmer (TR-Q6) is installed correctly.
Ensure that the Outfeed sensor Trimmer (TR-Q6) is clean.
Procedure
Enter the Service mode and select Outfeed sensor Trimmer (TR-Q6) in check sensors. Block, then unblock, the TR-Q6 with
a sheet of paper. The Outfeed sensor Trimmer (TR-Q6) sensor indicates :1 when the sensor is blocked and :0 when
the sensor is not blocked.
Y N
Go to TR-017 fault code.
Make sure that nothing interferes with the paper path.
TR-401
Fault Code TR-401, indicates that the Trim bin is full, or that the Trim bin full sensor TR-Q8 is faulty.
Procedure
Is there something blocking the Trim bin full sensor TR-Q8?
Y N
Go to TR-018 fault code.
Remove the object and empty the Trim bin.
TR-501
Fault Code TR-501, indicates that the Trim bin is full, or that the Trim bin full sensor TR-Q8 is faulty.
Procedure
Is there something blocking the Trim bin full sensor TR-Q8?
Y N
Go to TR-018 fault code.
Remove the object and empty the Trim bin.
TR-203
Fault Code TR-203, indicates that during Run, the Outfeed sensor trimmer (TR-Q6), was not blocked
within timeout.
Initial Actions
Check fuse F2 on Transformer.
Make sure that the Outfeed sensor trimmer (TR-Q6) is installed correctly.
Ensure that the Outfeed sensor trimmer (TR-Q6) is clean.
Procedure
Enter the Service mode and select Outfeed sensor trimmer (TR-Q6) in check sensors. Block, then unblock, the TR-Q6 with a
sheet of paper. The Outfeed sensor trimmer (TR-Q6) sensor indicates :1 when the sensor is blocked and :0 when the
sensor is not blocked.
Y N
Go to TR-017 fault code.
Make sure that nothing interferes with the paper path.
TR-205
Fault Code TR-205, indicates that the Infeed shaft or the Outfeed compressing bracket not is in it’s
lower position or that control switch S2 or S3 is faulty.
Procedure
Is the Infeed shaft or the Outfeed compressing bracket lifted from it’s lower position?
Y N
Go to TR-016 fault code.
Lift Infeed/outfeed latch and make sure that the Infeed shaft and the Outfeed compressing bracket is in it’s lower position.
