8.5
SPORTSMAN TRANSMISSION
8
Transmission Exploded View Table
REF.
Q
TY
DESCRIPTION REF.QTY.DESCRIPTION
1 1 Nylon Lock Nut 35 1 Output Front Cover
2 1 Shift Drum Bell Crank 36 15 Hex Screw
3 8 Hex Screw 37 1 Gear Set, Lapped Bevel, 10T/31T
4 1 Sector Cover 38 1 Ball Bearing, includes 56, 61, 67
5 1 O-ring 39 1 Spacer
6 1 Detent Pawl 40 1 Retaining Ring
7 1 Compression Spring 41 1 Center Drive Bearing Cover
8 1 Shift Shaft 42 4 Torx Screws
9 1 31T Sector Gear 43 1 56T Helical Gear
10 2 Hollow Hex Plug 44 4 Ball Bearing
11 2 Triple Lip Seal 45 1 12 Face Park Plate
12 1 Main Gearcase 46 1 6 Face Park Engagement Dog
13 1 Vent Tube 47 2 Wave Spring
14 1 O-ring 48 3 6 Face Engagement Dog
15 1 Shift Drum 49 2 Retaining Ring
16 1 Retaining Ring 50 2 Washer
17 1 6 Pin Rotary Switch 51 1 33T- 6 Face Gear
18 1 O-ring 52 3 Needle Split Cage Bearing
19 1 Detent Star 53 1 Reverse Shaft
20 1 Lockout Disc 54 1 24T, 6 Face
21 1 16T Sector Gear 55 1 Washer
22 2 Hex Nut 56 1 28T, 6 Face Gear, Includes 38, 61, 67
23 4 Dowel Pin 57 1 51T Mid Output Helical Gear
24 1 Plain Bearing 58 2 Shift Fork
25 4 Ball Bearings 59 1 Shift Shaft Rail
26 1 22T/18T Sprocket 60 1 Silent Chain
27 1 22T/22T Spline Sprocket 61 1 Input Shaft Sub- Assy, Includes 38, 56, 67
28 1 Silent Chain 62 1 LH Main Cover
29 1 Thrust Washer 63 1 Dual Lip Seal
30 1 Vent Plug 64 1 Transmission Mount Bracket
31 1 Front Main Output Shaft 65 2 Hex Screw
32 1 Shim, 2.0 x 1.5 66 1 Oil Fill Check Label
33 1 Thrust Button 67 1 Transmission Label
34 1 Shim, .450 x .265
To Next Page
