Polaris 2009 RANGER 700 User Manual

1.9
GENERAL INFORMATION
1
MODEL: 2009 RANGER 6X6
MODEL NUMBER: R09RF68AF, AR
ENGINE MODEL: EH68OLE
CLUTCH CHART
Engine
Platform
Polaris Domestic Twin Cylinder,
Liquid Cooled, 4-Stroke
Engine Model Number EH068OLE048
Engine Displacement 683cc
Number of Cylinders 2
Bore & Stroke (mm) 80 x 68 mm
Compression Ratio 9.40:1
Compression Pressure 150-170 psi
Engine Idle Speed 1150 ± 100 RPM
Lubrication Pressurized Wet Sump
Oil Requirements PS-4 PLUS 2W-50 Synthetic
Oil Capacity 2 qts. / 1.9 L
Coolant Capacity 3.25 qts. (3.08 L)
Overheat Warning Instrument Cluster Indicator
Exhaust System 2 to 1 Canister Style
Fuel System
Fuel System Type Bosch Electronic Fuel Injection
Fuel Delivery Electronic Fuel Pump (in tank)
Fuel Pressure 39 psi
Fuel Filters See Chapter 4
Fuel Capacity / Requirement
9 gal. (34 L)
87 Octane (minimum)
Electrical
Alternator Max Output 500 Watts @ 3000 RPM
Lights: Main Headlights 2 - Single Beam 50W / Halogen
Tail 5 Watts x 2
Brake 5 Watts x 2
Indicator Panel Lights 1 Watt (ea.)
Starting System Electric Start
Ignition System Bosch EFI (ECU Controlled)
Ignition Timing 7° BTDC @ 1200 RPM
Spark plug / Gap
Champion RC7YC3 /
.035 in. (0.9 mm)
Battery / Model / Amp Hr
Yuasa YB30L-B /
30 Amp Hr. / 12 Volt
Instrument Panel Type Multifunction Speedometer
DC Outlet Standard
Relays Fan / Power
Circuit Breakers Fan Motor: 15 Amp
Fuses
Main Chassis: 20 Amp
Accessory: 20 Amp
Power Relay: 15 Amp
ECU: 6 Amp
Drivetrain
Transmission Type Polaris Automatic PVT
Transmission Gear Ratio:
Front / Rear
High
Low
Reverse
4.43:1 / 3.83:1
10.08:1 / 8.71:1
6.87:1 / 5.94:1
Shift Type In Line Shift - H / L / N / R
Front Gearcase Oil Requirements
Polaris Demand Drive Fluid
5 oz. (150 ml)
Transmission Oil Requirements
Polaris Full Synthetic AGL
43.6 oz. (1290 ml)
Mid Gearcase Oil Requirements
Polaris ATV Angle Drive Fluid
6.75 oz. (200 ml)
Rear Gearcase Oil Requirements
Polaris ATV Angle Drive Fluid
10 oz. (300 ml)
Belt 3211118
Clutch Center Distance 10.05” (255 mm)
Steering / Suspension
Front Suspension MacPherson Strut
Front Travel 8 in. (20.3 cm)
Center Suspension Progressive Rate / Independent
Center Travel 5.25 in. (13.3 cm)
Rear Suspension Swing Arm w/Dual Shocks
Rear Travel 6.25 in. (16 cm)
Rear Shock Preload Adjustment Cam Adjustment
Toe Out 1/8 - 1/4 in. (3.2 - 6.35 mm)
Wheels / Brakes
Front Wheel Size 12 x 6 / 10 gauge
Middle / Rear Wheel Size 12 x 8 / 10 gauge
Front Tire
Make / Model / Size
Titan / AT489 / 25 x 10 R12
Middle / Rear Tire
Make / Model / Size
Titan / AT489 / 25 x 11 R12
Tire Air Pressure
Front / Middle / Rear
8 - 12 psi
Brakes / Brake Fluid 4 Wheel Hydraulic Disc / DOT 4
Parking Brake Hand Actuated (in dash)
Altitude Shift Weight Drive Spring
Driven
Spring
Meters
(Feet)
0-1500
(0-5000)
21-74
(5632117)
Red/Blue
(7043372)
Blk/Almd
(7043167)
1500-3700
(5000 - 12000)
21-70
(5632127)
Red/Blue
(7043372)
Blk/Almd
(7043167)
