3.14
ENGINE
Recommended Coolant
Use only high quality antifreeze/coolant mixed with distilled
water in a 50/50 or 60/40 ratio, depending on freeze protection
required in your area.
CAUTION: Using tap water in the cooling system will lead to
a buildup of deposits which may restrict coolant flow and reduce
heat dissipation, resulting in possible engine damage. Polaris
Premium 60/40 Antifreeze/Coolant is recommended for use in
all cooling systems and comes pre-mixed, ready to use.
Cooling System Pressure Test
1. Lift up the front hood.
2. Remove the pressure cap from the radiator and pressure test
the cooling system using a commercially available tester.
3. The system must retain 10 psi for five minutes or longer.
If pressure loss is evident within five minutes, check
radiator, all cooling system hoses and clamps and water
pump seal for leakage.
Radiator Cap Pressure Test
1. Remove radiator pressure cap and test using a cap tester
(commercially available).
2. The radiator cap relief pressure is 13 lbs. Replace cap if it
does not meet this specification.
Radiator
Water
Pump
Cylinder
Thermostat
Cylinder
Head
WARNING
Never remove radiator cap when engine is
warm or hot. The cooling system is under
pressure and serious burns may result.
Allow the engine and cooling system to cool
before servicing.
Radiator Cap
Coolant Flow Diagram
To Water Pump
Radiator
Surge Tank
From
Thermostat Housing
To Next Page
