2.17
MAINTENANCE
2
4. If particles are still suspected to be in the muffler, back the
machine onto an incline so the rear of the machine is one
foot higher than the front. Set the hand brake and block the
wheels. Make sure the machine is in Park and repeat Steps
2 and 3. SEE WARNING
5. If particles are still suspected to be in the muffler, drive the
machine onto the incline so the front of the machine is one
foot higher than the rear. Set the hand brake and block the
wheels. Make sure the machine is in Park and repeat Steps
2 and 3. SEE WARNING
6. Repeat steps 2 through 5 until no more particles are
expelled when the engine is revved.
7. Stop the engine and allow the arrestor to cool.
8. Reinstall the clean out plugs.
TRANSMISSION AND GEARCASES
Transmission Lubrication
NOTE: It is important to follow the transmission
maintenance intervals described in the Periodic
Maintenance Chart. Regular fluid level inspections
should be performed as well.
The transmission lubricant level should be checked and changed
in accordance with the maintenance schedule.
• Be sure vehicle is positioned on a level surface when
checking or changing the lubricant.
• Check vent hose to be sure it is routed properly and
unobstructed.
Transmission Lubricant Level Check
The fill plug is located on the right side of the transmission.
Access the fill plug from the rear right-hand side of the vehicle.
Maintain the fluid level even with the bottom threads of the fill
plug hole.
1. Position vehicle on a level surface.
2. Remove the fill plug and check the lubricant level.
3. If lubricant level is not even with the bottom threads, add
the recommended lubricant as needed. Do not overfill.
4. Reinstall the fill plug and torque to specification.
= T
Drain / Fill Plug Torque: 14 ft. lbs. (19 Nm)
