6
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
6.13
27.Place a block of wood under the transmission.
Remove the bolts securing the left and right
transmission mount plates to the engine and
transmission.
28.Remove the rear transmission mount from the
transmission and frame.
29.Slide transmission towards the rear of the vehicle. Lift
and rotate the top of the transmission towards the left
side of the vehicle. With the help of an assistant,
remove transmission from the top of the engine
compartment.
TRANSMISSION
