9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
1.13
CHAPTER 10 — BODY / FRAME
PART DESCRIPTION
TORQUE
SPECIFICATION
Skid Plate Fasteners 3.5 lb-ft (4.7 Nm)
T-25 Inner Door Panel
Fasteners
22 in-lbs (2.5 Nm)
T-40 Inner Door Panel
Fasteners
42 in-lbs (5 nm)
Terminal Block Fasteners
3 lb-ft (4 Nm)
Upper Front Fascia
Fasteners
3.5 lb-ft (4.7 Nm)
Visor Panel Fasteners
3.5 lb-ft (4.7 Nm)
CHAPTER 11 — ELECTRICAL
PART DESCRIPTION
TORQUE
SPECIFICATION
Battery Bracket
3.5 lb-ft (5 Nm)
Brake Switch 15 lb-ft (20 Nm)
CPS Retaining Bolt 9 lb-ft (12 Nm)
ETC Housing Retaining
Bolts
5 lb-ft (7 Nm)
ECT Sensor 17 lb-ft (23 Nm)
ECU Retaining Screws 24 lb-in (2.7 Nm)
Fuse Box Fasteners
35 lb-in (4 Nm)
Ignition Coil Retaining
Bolt
8 lb-ft (11 Nm)
Instrument Cluster to
Mounting Bracket
Fasteners
30 lb-in (3.4 Nm)
Instrument Cluster
Mounting Bracket to
Vehicle Fasteners
3.5 lb-ft (4.7 Nm)
Intake Boot Clamp 49 lb-in (5.5 Nm)
Oxygen Sensor 13 lb-ft (18 Nm)
Pulse Bar Bracket
Fasteners
60 in-lbs (7 Nm)
Pulse Bar Cable Nuts 24 in-lbs (3 Nm)
Pulse Bar Fasteners Torque Until Fastener Is
Fully Seated
Spark Plug 7 lb-ft (10 Nm)
Speed Sensor 12 lb-ft (16 Nm)
Starter Motor Fasteners
7 lb-ft (10 Nm)
Tail Light Fasteners
4 lb-ft (5 Nm)
CHAPTER 11 — ELECTRICAL
PART DESCRIPTION
TORQUE
SPECIFICATION
Terminal Block Fasteners
3 lb-ft (4 Nm)
T-MAP Mounting Bolt
40 lb-in (4.5 Nm)
TPS Mounting Fasteners 8 lb-ft (11 Nm)
Winch Fasteners
16 lb-ft (22 Nm)
Winch Mounting Bracket 30 lb-ft (41 Nm)
