10.32

9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual

9. Remove the fasteners holding the rear fender to the

vehicle and rocker panel. Pull the rear fender from the

tabs holding it to the vehicle.

NOTICE

Remove the clutch intake hose from the LH rear fender.

10.Remove the remaining fasteners on the rocker panel

and remove the panel from the vehicle.

NOTICE

Remove the gas cap to remove the RH rocker panel.

11. Remove the fasteners holding the lower front fascia

to the vehicle. Remove the lower front fascia from the

vehicle.

12.Remove the remaining fasteners holding the upper

front fascia to the vehicle and the hood liner.

Disconnect the headlights from the electrical harness

and remove the front fascia from the vehicle.

13.To remove the hood liner, remove the fasteners and

clamps securing the terminal block, intake vent, and

coolant expansion bottle.

BODY / FRAME
