11. Install the fasteners holding the rear center console to
the vehicle.
12.Install the fasteners holding the rear center console
cover to the vehicle. Install the accessory power
outlet.
13.Install the center console top into the vehicle and over
the shift lever. Install the shift boot into the center
console top. Connect the 12 V power receptacles to
the wiring harness.
14.Install the fasteners holding the RH and LH center
console panels to the vehicle. Torque fasteners to
specification.
TORQUE
Center Console Panel Fasteners:
3.5 lb-ft (4.7 Nm)
15.Install the center tunnel access cover and fasteners
securing it to the RH and LH center console panels.
BODY / FRAME
