5.12
BODY AND STEERING
10. Make sure that the routing of the vent line is correct.
11. Place the fuel tank bracket in place. Note to get the routing
of the throttle cable and carburetor venting correct.
12. Tighten the fuel tank bracket fasteners.
13. Hook up the fuel line to the fuel pump and move the clamp
to the correct area.
STEERING / A-ARM
Exploded View
NOTE: To avoid damage to tie rods and other
steering components, be sure to install tie rod end
bolts in the proper direction. The steering post arm
bolt (B) points up; the rod end bolts (A) point down.
Be sure inner rod ends are placed between the
B
