MAINTENANCE
2.20
14. Clean the filter sealing area on the engine.
15. Lubricate the filter o-ring. Check to make sure the o-ring is
in good condition.
16. Install the new oil filter, After the filter contacts the engine
surface turn it 1/2 turn by hand.
17. Remove the dipstick.
18. Add 0W/50 oil.
19. Reinstall the dipstick.
20. Start the engine and allow it to idle for two minuets.
21. Turn off the engine. Check for oil leaks.
22. Check the oil level. Add oil as needed to bring the level
between the min. and max marks. Do not overfill.
23. Discard used oil and filter properly.
VALVE CLEARANCE ADJUSTMENT
INTAKE VALVE CLEARANCE
1. Verify cam lobes are pointed down.
2. Insert a .006” (.15 mm) feeler gauge between end of intake
valve stem and adjuster screw.
3. When clearance is correct, hold adjuster screw and tighten
locknut securely.
4. Re-check the valve clearance.
5. Repeat adjustment procedure if necessary until clearance is
correct with locknut secured.
EXHAUST VALVE CLEARANCE
1. Verify cam lobes are pointed down.
2. Insert an .006” (.15 mm) feeler gauge between end of
exhaust valve stem and adjuster screw.
3. Loosen locknut and turn adjuster screw until there is a slight
drag on feeler gauge.
4. When clearance is correct, hold adjuster screw and tighten
locknut securely.
5. Re-check the valve clearance.
6. Repeat adjustment procedure if necessary until clearance is
correct with locknut secured.
STEERING
The steering components should be checked periodically for
loose fasteners, worn tie rod ends, and damage. Also check to
make sure all cotter pins are in place. If cotter pins are
removed, they must not be re-used. Always use new cotter pins.
INTAKE/ EXHAUST VALVE CLEARANCE
.006” (.15 mm)
