FINAL DRIVE
AWD FRONT DRIVE AXLE EXPLODED VIEW
Front Drive Shafts and Propshafts
NOTE: Refer to your parts manual for the proper replacement parts.
Drive Axle Components
Drive Boot Replacement Kits
Front Prop Shaft Components
Outer Clamp
Boot
Clamp
4 oz. grease
Propshaft Assy.
Cross & Bearing Kit
Prop Shaft
Yoke, Prop to Transmission
Yoke, Front Gearcase
4 oz
Clamps
Outer CV Joint
Inner Boot
Inner CV Joint
Outer Boot
Shaft
