3.4
ENGINE
TORQUE PATTERNS
Tightening method for cylinder head nuts:
1) Apply engine oil to washer and threads of 10mm bolts.
2) Tighten 10mm bolts in pattern below to 18.5 ft. lbs. (25
Nm)
3) Loosen 180 degrees
4) Tighten to 11 ft. lbs. (15 Nm)
5) Tighten 90 degrees
6) Tighten 60 degrees
7) Tighten 6mm head and base bolts to 8 ft. lbs. (11 Nm)
2
4
5
6
1
6 mm
Cylinder Head / Cylinder Base
3
