3.8
ENGINE
KEY - Std: Standard; OS: Oversize; ID: Inner Diameter; OD: Outer Diameter; Mag: Magneto Side;
PTO: Power Take Off.
Crankshaft / Counter Balancer / Oil Pump ES300PFE010
Crankshaft
Crankshaft End Runout Limit 0.0024" (0.06 mm)
Crankshaft End Play
Std 0.006-.012" (.15 - .30 mm)
Limit N/A
Counter Balancer Counter Balancer Shaft End Play
Std 0.004-.029" (0.1 - .74 mm)
Limit N/A
Oil Pump
Oil Pump Shaft End Play N/A
Oil Pump End Clearance
Std 0.0027-.0051" (.070 - .130 mm)
Limit N/A
Pump Rotor Tip Clearance
Std 0.0047" (.12 mm)
Limit N/A
Pump Feed Rotor to Pump Body
Clearance
Std 0.006 - 008" (.15 - .21 mm)
Limit N/A
Oil Pressure (Polaris 0W-50 @
Normal Operating Temperature @ Idle
Speed)
Std Above 9 PSI
Limit Below 9 PSI
