www.poolpak.com | 800-959-772548 | MPK Series - Installation, Operation and Maintenance
Table 4-2. Remote ACC Refrigerant (R-410A) Charge
Table 4-3. Refrigerant (R-410A) Charge for Different Line Sizes
(based on 120oF saturated condensing temperature)
Refrigerant and Oil Charging:
• PoolPak units are shipped with the required charge for self contained operation only. The remote ACC option
does NOT provide the refrigerant charge or oil required for the ACC and line sets.
• Refer to the below remote ACC and line size charging charts to calculate the additional charge required.
• For the additional oil required, multiply 2% by the total additional refrigerant charge (ACC and lineset length).
For Bitzer compressors, use Idemitsu FVC32D PVE Oil.
• Contact Factory for additional help or verifying the additional refrigerant charge.
Above chart is for lineset length less than 100 ft and ACC located less than 50 ft above unit or 20 ft below unit.
Failures due to a piping layout not within these limits nor receiving prior PoolPak Factory approval
will not be covered under PoolPak warranty.
WARNING!
ACC Model # Circuit #1 (lbs) Circuit #2 (lbs) Circuit #3 (lbs)
MAC0532 30 30 -
MAC0602 30 30 -
MAC0682 30 35 -
MAC0742 30 35 -
MAC0842 30 45 -
MAC1003 30 30 30
MAC1163 30 35 35
MAC1353 35 35 45
MAC1483 35 45 45
Tube OD
(inches)
Wall thickness
(inches)
Tubing Type
Discharge
(lb/ft)
Liquid
(lb/ft)
7/8 0.045 L 0.021 0.192
1 1/8 0.05 L 0.036 0.327
1 3/8 0.055 L 0.055 0.499
1 5/8 0.072 K 0.076 0.684
