• Ctl Gain – Control Gain – 065.0 kCFM (Range 0 to 999.9)
• Ctl Int Time – Control Integral Time – 003 s (Range 0 to 999)
• Ctl Der Time – Control Derivative Time – 000 s (Range 0 to 999)
• Ctl Upd Time – Control Update Time – 05000 ms (Range 0 to 32767)
• Ctl Anti-Bump – Control Anti-Bump? Off or On
Exhaust Fan – Exhaust Fan Configuration
• Minimum kCFM – Minimum Airflow – 05.5 kCFM (Range 0 to 99.9)
• Maximum kCFM – Maximum Airflow – 11.0 kCFM (Range 0 to 99.9)
• Run Cur Tol – Fan Proof Current – 002.5 A (Range 0 to 999.9) D cabinet only
• Run Cur Dly – Time Delay to Prove Current – 05 s (Range 0 to 99) D cabinet only
• Purge Speed – The speed (RPM) of the exhaust fan during purge. – 1590 RPM (Range 30 to 1800)
• Exh Fan Spd – Exhaust Fan Speed Control Setting –
• CFM Setp – This mode indicates that the fan speed or outside air damper position will be controlled
to maintain airflow at CFM set points.
• OAD%/Spd – This mode indicates that the exhaust fan speed will be controlled by setting
the RPM set points based on the amount of outside air in the supply air.
• Exh/OA Offs – Exhaust Air/Outside Air Offset – 7. 0 % (Range -20.0 to 20.0)
• RemExhVol – Remote Exhaust Fan Air Volume – 00.0 kCFM (Range -50.0 to 50.0)
If CFMSetp selected, set the below set points:
• Min Ctl Spd – Minimum Control Speed – 0540 RPM (Range 0 to 2000)
• Max Ctl Spd – Maximum Control Speed – 1950 RPM (Range 0 to 3000)
Contact Factory before adjusting the below values:
• Ctl Dband – Control Deadband – 00.0 kCFM (Range 0 to 10.0)
• Ctl Gain – Control Gain – 020.0 kCFM (Range 0 to 999.9)
• Ctl Int Time – Control Integral Time – 003 s (Range 0 to 999)
• Ctl Der Time – Control Derivative Time – 000 s (Range 0 to 999)
• Ctl Upd Time – Control Update Time – 05000 ms (Range 0 to 32767)
• Ctl Anti-Bump – Control Anti-Bump? Off or On
If OAD%/Spd selected, set the below set points:
• Unocc 1-7 (Unoccupied Mode Stages 1 to 7) – (Range 0 to 100%/ 0 to 2000 RPM)
1. 000.0%/0787 RPM
2. 015.0%/0787 RPM
3. 030.0%/0787 RPM
4. 045.0%/0900 RPM
5. 060.0%/0950 RPM
6. 070.0%/1000 RPM
7. 100.0%/1100 RPM
• Occ 1-7 (Occupied Mode Stages 1 to 7) – (Range 0 to 100%/ 0 to 2000 RPM)
1. 000.0%/0609 RPM
2. 015.0%/0609 RPM
3. 030.0%/0609 RPM
4. 045.0%/0620 RPM
5. 060.0%/0753 RPM
6. 070.0%/1000 RPM
7. 100.0%/1107 RPM
Purge Fan – Purge Fan Configuration
• Minimum kCFM – Minimum Airflow – 11.0 kCFM (Range 0 to 99.9)
• Maximum kCFM – Maximum Airflow – 21.6 kCFM (Range 0 to 99.9)
• Run Cur Tol – Fan Proof Current – 002.5 A (Range 0 to 999.9) D cabinet only
To Next Page
