PoolPak MPK series - Page 67

© 2017 PoolPak LLC. All rights reserved. MPK Series - Installation, Operation and Maintenance | 67
PoolPak
®
MPK Series IOM
• Run Cur Dly – Time Delay to Prove Current – 05 s (Range 0 to 99) D cabinet only
• Purge Speed – The speed (RPM) of the purge fan during purge – 1811 RPM (Range 30 to 1800)
• Pur Fan Spd – Purge Fan Speed Control Setting –
• Flow Ctl – This mode indicates that the fan speed or outside air damper position will be controlled
to maintain airflow at CFM set points.
• RPM Setp – This mode indicates that the purge fan speed will be controlled by setting
the supply fan RPM set points.
• Purge Min OAT – minimum allowable outside air temperature during purge (°F) – 40.0°F (Range -40.0 to 99.9)
• Enab Prg Min OAT – Enable the Purge Min OAT limit YES or No
• Min Ctl Spd – Minimum Control Speed – 0540 RPM (Range 0 to 2000)
• Max Ctl Spd – Maximum Control Speed – 1950 RPM (Range 0 to 3000)
Contact Factory before adjusting the below values:
• Ctl Dband – Control Deadband – 00.0 kCFM (Range 0 to 10.0)
• Ctl Gain – Control Gain – 100.0 kCFM (Range 0 to 999.9)
• Ctl Int Time – Control Integral Time – 003 s (Range 0 to 999)
• Ctl Der Time – Control Derivative Time – 000 s (Range 0 to 999)
• Ctl Upd Time – Control Update Time – 05000 ms (Range 0 to 32767)
• Ctl Anti-Bump – Control Anti-Bump? Off or On
Compr Sys – Compressor System Configuration
• Cpr 1 Enabled – Compressor Module 1 Enabled? Yes or No
• Cpr 2 Enabled – Compressor Module 2 Enabled? Yes or No
• Cpr 3 Enabled – Compressor Module 3 Enabled? Yes or No
• Cpr Air Cool – Compressor Air Cooling Mode Enabled? Enabled or Disabled
• Cpr Air Heat – Compressor Air Heating Mode Enabled? Enabled or Disabled
• Cpr Wtr Heat – Compressor Water Heating Mode Enabled? Enabled or Disabled
• Cpr Cool Min OAT – The minimum allowable outside air temperature during
compressor cooling (°F) – 62.0 °F (Range 0 to 99.9)
• Stage 1 Cpr Cfg – Which compressor module(s) to enable for Stage 1?
Default: 1 (Range None, 1, 2, 3, 1&2, 1&3, 2&3, 1&2&3)
• Stage 2 Cpr Cfg – Which compressor module(s) to enable for Stage 2?
Default: 1&2 (Range None, 1, 2, 3, 1&2, 1&3, 2&3, 1&2&3)
• Stage 3 Cpr Cfg – Which compressor module(s) to enable for Stage 3?
Default: 1&2&3 (Range None, 1, 2, 3, 1&2, 1&3, 2&3, 1&2&3)
• Stage 4 Cpr Cfg – Which compressor module(s) to enable for Stage 4?
Default: 1&2&3 (Range None, 1, 2, 3, 1&2, 1&3, 2&3, 1&2&3)
Dampers
Outside Air – Outside Air Damper
• Pos Correction – Damper Position Correction based on damper feedback readings Yes or NO
• Flow Ctl – Type of damper flow control –
• % Open – Correlates the Mixing Box % or percent of OA that makes up supply air to the OA damper
• CFM Setp – This mode indicates that the outside air damper position will be controlled to maintain airflow
at CFM set points.
Contact Factory before adjusting the below values:
• Ctl Gain – Control Gain – 000.0 kCFM (Range 0 to 999.9)
• Ctl Int Time – Control Interval Time – 030 s (Range 0 to 999)
• Ctl Der Time – Control Derivative Time – 000 s (Range 0 to 999)
• Ctl Dband – Control Deadband – 00.0 kCFM (Range 0 to 99.9)
• Ctl Upd Time – Control Update Time – 05000 ms (Range 0 to 32767)
• Ctl Anti-Bump – Control Anti-Bump? Off or On
