www.poolpak.com | 800-959-772568 | MPK Series - Installation, Operation and Maintenance
If % Open selected, set the below set points:
• MB%/OA% 1-7 (Mixing Box %/ Outside Air % Stages 1 to 7) – (Range 0 to 100.0%)
1. 000.0/000.0
2. 015.0/030.0
3. 020.0/035.0
4. 030.0/045.0
5. 050.0/060.0
6. 075.0/080.0
7. 100.0/100.0
Recirc Air – Recirculation Air Damper
• Pos Correction – Damper Position Correction based on damper feedback readings Yes or NO
• Point 1- Point 7 OAD%, RAD% - OA damper position to RA damper position Stages 1 to 7.
1. 000.0%/100.0%
2. 030.0%/070.0%
3. 045.0%/055.0%
4. 055.0%/045.0%
5. 065.0%/035.0%
6. 085.0%/020.0%
7. 100.0%/000.0%
Evap Bypass – Evaporator/Bypass Air Damper
• HighSHR Evap kCFM – High Sensible Heat Recovery Evaporator Coil Airflow – 24.7 kCFM (Range 0 to 99.9)
• LowSHR Evap kDFM – Low Sensible Heat Recovery Evaporator Coil Airflow – 20.2 kCFM (Range 0 to 99.9)
• Point X1,Y1 to X7, Y7 % Open per Airflow kCFM – Damper Position per Airflow (Range 0 to 99.9)
X1: 00.0 kCFM Y1: 00.0%OP
X2: 02.4 kCFM Y2: 30.0%OP
X3: 06.7 kCFM Y3: 50.0%OP
X4: 10.7 kCFM Y4: 60.0%OP
X5: 16.0 kCFM Y5: 70.0%OP
X6: 19.6 kCFM Y6: 80.0%OP
X7: 27.7 kCFM Y7: 99.9%OP
Pool Water Heating
• Cmpr Wtr Heat – Enable Compressor Pool Water Heating? Enabled or Disabled
• Smart Pump – Enable Smart Pump Control? Enabled or Disabled
• Smart Pump Frz Pro – Enable Freeze Protection when using Smart Pump Control? Yes or No
• Circ A Min PD – Circuit A Minimum Water Flow Pressure Differential in order to run pool water heating – 08.3’
W.C. (Range 0 to 99.9)
• Circ B Min PD – Circuit B Minimum Water Flow Pressure Differential in order to run pool water heating – 08.3’
W.C. (Range 0 to 99.9)
• A On/Off DB – Circuit A On/Off Deadbands – 00.0/01.8’ (Range 0 to 99.9)
• B On/Off DB – Circuit A On/Off Deadbands – 00.0/01.8’ (Range 0 to 99.9)
• Pool1 Cpr DB – On/Off Deadbands for Compressor Pool Water Heating of Pool 1 – 0.2 /0.5 (Range -9.9 to 9.9)
• Pool2 Cpr DB – On/Off Deadbands for Compressor Pool Water Heating of Pool 2 – 0.2 /0.5 (Range -9.9 to 9.9)
• Pool1 Aux DB – On/Off Deadbands for Auxiliary Pool Water Heating of Pool 1 – 0.7 /-0.2 (Range -9.9 to 9.9)
• Pool2 Aux DB – On/Off Deadbands for Auxiliary Pool Water Heating of Pool 2 – 0.7 /-0.2 (Range -9.9 to 9.9)
Aux Air Heating – Auxiliary Air Heating Configuration
• Sys Type – Type of Auxiliary Heating System Installed
• None – No Aux Heat Installed
