PoolPak
®
MPK Series IOM
• LPHW – Low Pressure Hot Water Heat
• Elec – Electric Aux Heat
• Gas – Gas Aux Heat
• Steam – Steam Coil Aux Heat
• Frz Stat Inst – Freeze Stat Installed? Yes or No
• Stages Installed – Number of Aux Heat Stages Installed – 5 (Range 0 to 5)
• Aux Heat First – Yes or No – This parameter determines if the Auxiliary Heat or compressor is the first stage of
space heating. On a call for both space heating and dehumidification, compressor will always be first.
• Ctl Type – Control Type setting for the Auxiliary Heat System – Staged or Disch Air Tmp (Control based on
• Discharge Air Temperature)
• Stg 1-5 Setp – Stage 1-5 Setpoints for staging aux heat capacity (Range 0 to 100%)
1. 020.0%
2. 040.0%
3. 060.0%
4. 080.0%
5. 100.0%
• Min Sply Tmp – Minimum Supply Temperature – 40.0°F (Range 0 to 99.9)
• FrzAlmClearDly – Freeze Alarm Clear Delay (sec) – 0900 s (Range 30 to 9999)
• Sys Fail Detect – System Fail Detect Enabled? (gives an alarm if the aux system is on but does not satisfy the
Minimum Temperature Rise) Yes or No
• Failure Delay – Time delay before a failure is reported – 300 s (Range 0 to 999)
• Min Temp Rise – Minimum Temperature Rise (°F) – 10.0°F (Range 0 to 99.9)
• Stage 1-5 Offset (Range 0 to 100.0)
1. 005.0
2. 010.0
3. 015.0
4. 020.0
5. 025.0
• Min Ctl Pct Outp – Minimum Control Percentage Output – 000.0 (Range 0 to 999.9)
• Max Ctl Pct Outp – Maximum Control Percentage Output – 100.0 (Range 0 to 999.9)
Contact Factory before adjusting the below values:
• Ctl Gain – Control Gain – 065.0°F (Range 0 to 999.9)
• Ctl Int Time – Control Integral Time – 030 s (Range 0 to 999.9)
• Ctl Der Time – Control Derivative Time – 000 s (Range 0 to 999.9)
• Ctl Dband – Control Deadband – 00.0°F (Range 0 to 10.0)
• Ctl Upd Time – Control Update Time – 10000 ms (Range 0 to 32767)
• Ctl Anti-Bump – Control Anti-Bump? Off or On
Aux Air Cooling – Auxiliary Air Cooling Configuration
• Sys Type – Type of Auxiliary Cooling System – None or CHW (Chilled Water Coil)
• Frz Stat Inst – Freeze Stat Installed? Yes or No
• Stages Installed – Number of Aux Cool Stages Installed – 0 (Range 0 to 5)
• Aux Cool First – Yes or No – This parameter determines if the Auxiliary Cooling system or compressor is the first
stage of space cooling. On a call for both space cooling and dehumidification, compressor will always be first.
