www.poolpak.com | 800-959-772570 | MPK Series - Installation, Operation and Maintenance
• Stg 1-5 Setp – Stage 1-5 Setpoints for staging aux cool capacity (Range 0 to 100.0)
1. 020.0%
2. 040.0%
3. 060.0%
4. 080.0%
5. 100.0%
• Min Sply Tmp – Minimum Supply Temperature – 40.0°F (Range 0 to 99.9)
• Sys Fail Detect – System Fail Detect (gives an alarm if the aux system is on but does not satisfy the Minimum
Temperature Drop) Yes or No
• Failure Delay – Time delay before a failure is reported – 300 s (Range 0 to 999)
• Min Temp Drop – Minimum Temperature Drop (°F) – 10.0°F (Range 0 to 99.9)
Aux Air Dehum – Auxiliary Air Dehumidification System Configuration
• Aux CW/HW Deh – Auxiliary Chilled Water/Hot Water Dehumidification Enabled? Enabled or Disabled
• OAT Trigger Temp – Minimum Differential Temperature between Outside Air and Return before auxiliary
dehumidification system will be enabled – 20.0°F (Range 0 to 50.0F)
• Aux Dehum First – Yes or No – This parameter determines if the Auxiliary Dehumidification system or compressor
is the first stage of dehumidification.
Space Temp Ctl – Space Temperature Control Setting
• F/W Cool - Flywheel Air Cooling mode - 00.0 (Range 00.0 to 30.0) - This parameter controls the PoolPak
flywheel air conditioning feature. A setting of 00.0 disables flywheel cooling. A setting of 05.0 or greater
activates flywheel cooling. The parameter value is the number of degrees that the space temperature is allowed
to drop below the set point while cooling the pool during the unoccupied period.
• Select either ECCII Fuzzy Dly or PID Delay. Contact Factory before adjusting the below values
If ECCII Fuzzy Dly selected:
• Base Stg Delay – Base Stage Delay (min) – 08.0 min (Range 1.0 to 20.0)
• Fuzzy Max Rate – A fuzzy logic parameter – 04 (Range 1 to 10)
• Fzy Calc Period – A fuzzy logic parameter – 20 s (Range 10 to 99)
If PID Delay selected:
• Control Band – 250.0 °F (Range 10.0 to 999.9)
• Int Time – 0120 s (Range 0 to 3000)
• Der Time – 0300 s (Range 0 to 9999)
• Update Time – 10000 ms (Range 0 to 32767)
• Base Dly Tim – 06.0 min (Range 1.0 to 20.0)
Dew Point Control – Dew Point Control Setting
Select either ECCII Fuzzy Dly or PID Delay. Contact Factory before adjusting the below values
If ECCII Fuzzy Dly selected:
• Base Stg Delay – Base Stage Delay (min) – 08.0 min (Range 1.0 to 20.0)
• Fuzzy Max Rate – A fuzzy logic parameter – 04 (Range 1 to 10)
• Fzy Calc Period – A fuzzy logic parameter – 20 s (Range 10 to 99)
If PID Delay selected:
• Control Band – 250.0 °F (Range 10.0 to 999.9)
• Int Time – 0120 s (Range 0 to 3000)
• Der Time – 0300 s (Range 0 to 9999)
• Update Time – 10000 ms (Range 0 to 32767)
• Base Dly Tim – 06.0 min (Range 1.0 to 20.0)
