POSEIDON Jetstream Service Manual

JETSTREAM
1.0:E7
Poseidon Jetstream
BREATHING REGULATOR Art. No 2960
USA: Poseidon Odin
Primary pressure ................................................................................Max. 4350 PSI / 300 bar
Secondary pressure ..........................................................................Max. 145 PSI 10 bar
Air flow .................................................................................................Approx. 1600 l/min
Inhalation resistance ........................................................................Max. 40 mm of water
Exhalation resistance .......................................................................Max. 20 mm of water
The above data apply when measuring at atmospheric pressure
FIRST STAGE VALVE Art. No 2962, 3580
Description...........................................................................................Diaphgram- actuated balanced with shear
venturi boost.
Connecting threads for primary pressure................................G5/8'' -max. 4350 PSI/ 300 bar accord.
SS 2600/K and DIN 477/5 or yoke connection
accord. SS 2603 and ANSI/CGA V1: 1987
Outlet connections:
One outlet marked R for second stage (max. airflow) .........UNF 3/8’’ -secondary pressure
Three outlets marked LP for drysuits,
buoyancy compensators, hookah suppply
safety second stage,etc...................................................................UNF 3/8’’-secondary pressure
One outlet marked S has restricted airflow and
therefore is intended only for dry-suit or stabjacket ...........Intended for first stage No 3580
UNF 3/8’’-secondary pressure
One outlet marked HP for pressure gauge..............................UNF 7/16’’- primary pressure
SECOND STAGE VALVE Art. No. 2961, 3546
Description...........................................................................................Upstream diaphragm actuated. servo assisted
with safety relief, fixed ejector system.
Purge button for clearing.
Sensivity switch for added control.
REGULATOR HOSE WITH INTEGRAL SAFETY VALVE
Length....................................................................................................28 inch / 70 cm
Release pressure ................................................................................Approx. 247 PSI / 17 bar
TIGHTENING TORQUE
Primary connection ..........................................................................20 - 22 Ibf.ft / 28 - 30 Nm
Valve cover ...........................................................................................20 - 22 Ibf.ft / 28 - 30 Nm
Connections marked R-LP-HP.......................................................6 Ibf.ft / 8 Nm
Balanced housing .............................................................................7 Ibf.ft / 10 Nm
ANTI-FREEZE PROTECTION
Type designation ...............................................................................Art. No 1286
Type ........................................................................................................Rubber cap
